| Product General Characteristic | |
|---|---|
| Product Overview | Gen Z Right Angle 1C Connector |
| Component Type | Receptacle |
| PCB Mount Type | SMT |
| Orientation | Right Angle |
| Physical Characteristic | |
|---|---|
| Housing Material | LCP |
| Contact Material | C7025 |
| Plating Material on Contact Area | Au |
| Plating Thickness on Contact Area | 15u" |
| Circuits | 56 pin |
| Pitch | 0.60mm |
| Tail Length | 1.35mm |
| Locating Post | 1.10mm |
| Durability | 200 Cycles |
| Housing Color | Black |
| Electrical Characteristic | |
|---|---|
| Current Rating | 1.1A |
| Max. Voltage | AC 300V |
| Solder Process Characteristic | |
|---|---|
| Solder Process Type | IR Reflow |
| Max. Process Temperature | 260℃ |
| Duration at Max. Process Temperature | 10s |
| Environment Characteristic | |
|---|---|
| RoHS/ Halogen Free(HF) Compliance | HF |
| Others | |
|---|---|
| Packaging | Reel |
